Experimental studies of rip current systems induced by the intersecting waves near a groin

Yan Sheng; Zou Zhili; Xu Jie; Chang Chengshu; You Zaijin; Wang Dong

doi:10.12284/hyxb2023149

Volume 45 Issue 10

Oct. 2023

Turn off MathJax

Article Contents

Article Navigation > Haiyang Xuebao > 2023 > 45(10): 135-146

Yan Sheng，Zou Zhili，Xu Jie, et al. Experimental studies of rip current systems induced by the intersecting waves near a groin[J]. Haiyang Xuebao，2023, 45(10)：135–146 doi: 10.12284/hyxb2023149

Citation:

PDF( 2444 KB)

Experimental studies of rip current systems induced by the intersecting waves near a groin

doi: 10.12284/hyxb2023149

Yan Sheng^{1, 2, 3
,},
Zou Zhili^{2
,
,},
Xu Jie²,
Chang Chengshu²,
You Zaijin^{1, 3},
Wang Dong⁴

1.
College of Transportation Engineering, Dalian Maritime University, Dalian 116026, China
2.
State Key Laboratory of Coastal and Offshore Engineering, Dalian University of Technology, Dalian 116024, China
3.
Center for Ports and Maritime Safety, Dalian Maritime University, Dalian 116026, China
4.
College of Environmental Sciences and Engineering , Dalian Maritime University, Dalian 116026, China

Received Date: 2023-02-10
Rev Recd Date: 2023-06-10

Available Online: 2023-10-10

Publish Date: 2023-10-30

Abstract

Abstract

Rip currents are narrow and concentrated seaward-directed flows and play an important role on coastal morphodynamics, mass transport and swimmer safety. As the intersecting wave field caused by wave reflection of coastal structures is not uniform alongshore, the flow characteristics and spatial distribution of rip currents are different from those of uniform intersecting waves on an open coast. The reflection of waves on cross-shore coastal structures will lead to longshore standing waves, and rip currents will occur in the area of standing wave nodes because of the small wave height, which is one of the generation mechanisms for rip currents. In this study, the characteristics of rip current systems near a coastal structure on a barred beach are given by a laboratory experiment. The influence of the longshore variation of wave height on the flow balance of each rip current unit is discussed. The results showed that the existence of structure drives a longshore current away from the structure and causes the water exchange between each rip current unit. The lateral currents between rip current units are found to make contributions to the rip current transport of each rip current unit and the contributions mainly depend on the relative position of the unit to the structure.
- rip current system,
- intersecting waves,
- barred beach,
- coastal structures,
- physical experiments

FullText(HTML)

References(26)

References

[1]	Castelle B, Scott T, Brander R W, et al. Rip current types, circulation and hazard[J]. Earth-Science Reviews, 2016, 163: 1−21. doi: 10.1016/j.earscirev.2016.09.008
[2]	McCarroll R J, Brander R W, Turner I L, et al. Lagrangian observations of circulation on an embayed beach with headland rip currents[J]. Marine Geology, 2014, 355: 173−188. doi: 10.1016/j.margeo.2014.05.020
[3]	MacMahan J H, Thornton E B, Reniers A J H M. Rip current review[J]. Coastal Engineering, 2006, 53(2/3): 191−208.
[4]	Brewster B C, Gould R. Comment on “Rip current related drowning deaths and rescues in Australia 2004−2011” by Brighton et al. (2013)[J]. Natural Hazards and Earth System Sciences, 2014, 14(8): 2203−2204. doi: 10.5194/nhess-14-2203-2014
[5]	Short A D, Hogan C L. Rip currents and beach hazards: their impact on public safety and implications for coastal management[J]. Journal of Coastal Research, 1994(12): 197−209.
[6]	Woodward E, Beaumont E, Russell P, et al. Analysis of rip current incidents and victim demographics in the UK[J]. Journal of Coastal Research, 2013, 65(10065): 850−855.
[7]	Gallop S L, Bryan K R, Coco G, et al. Storm-driven changes in rip channel patterns on an embayed beach[J]. Geomorphology, 2011, 127(3/4): 179−188.
[8]	Thornton E B, MacMahan J, Sallenger Jr A H. Rip currents, mega-cusps, and eroding dunes[J]. Marine Geology, 2007, 240(1/4): 151−167.
[9]	Loureiro C, Ferreira Ó, Cooper J A G. Extreme erosion on high-energy embayed beaches: influence of megarips and storm grouping[J]. Geomorphology, 2012, 139−140: 155−171. doi: 10.1016/j.geomorph.2011.10.013
[10]	Dalrymple R A, Lanan G A. Beach cusps formed by intersecting waves[J]. GSA Bulletin, 1976, 87(1): 57−60. doi: 10.1130/0016-7606(1976)87<57:BCFBIW>2.0.CO;2
[11]	Dalrymple R A. A mechanism for rip current generation on an open coast[J]. Journal of Geophysical Research, 1975, 80(24): 3485−3487. doi: 10.1029/JC080i024p03485
[12]	Wei Zhangping, Dalrymple R A, Xu Munan, et al. Short-crested waves in the surf zone[J]. Journal of Geophysical Research: Oceans, 2017, 122(5): 4143−4162. doi: 10.1002/2016JC012485
[13]	Kirby J T, Derakhti M. Short-crested wave breaking[J]. European Journal of Mechanics-B/Fluids, 2019, 73: 100−111. doi: 10.1016/j.euromechflu.2017.11.001
[14]	Choi J, Roh M. A laboratory experiment of rip currents between the ends of breaking wave crests[J]. Coastal Engineering, 2021, 164: 103812. doi: 10.1016/j.coastaleng.2020.103812
[15]	Shin C H, Noh H K, Yoon S B, et al. Understanding of rip current generation mechanism at Haeundae Beach of Korea: honeycomb waves[J]. Journal of Coastal Research, 2014, 72(S1): 11−15.
[16]	Long J W, Özkan-Haller H T. Offshore controls on nearshore rip currents[J]. Journal of Geophysical Research: Oceans, 2005, 110(C12): C12007. doi: 10.1029/2005JC003018
[17]	Zhang Yu, Shi Fengyan, Kirby J T, et al. Phase-resolved modeling of wave interference and its effects on nearshore circulation in a large ebb shoal-beach system[J]. Journal of Geophysical Research: Oceans, 2022, 127(10): e2022JC018623. doi: 10.1029/2022JC018623
[18]	王彦, 邹志利. 平直沙坝海岸叠加波浪的裂流试验[J]. 水科学进展, 2023, 26(1): 123−129. doi: 10.14042/j.cnki.32.1309.2015.01.016 Wang Yan, Zou Zhili. Experimental study of rip currents by intersecting wave on barred beach[J]. Advances in Water Science, 2023, 26(1): 123−129. doi: 10.14042/j.cnki.32.1309.2015.01.016
[19]	Islam M R, Zhu D Z. Kernel density-based algorithm for despiking ADV data[J]. Journal of Hydraulic Engineering, 2013, 139(7): 785−793. doi: 10.1061/(ASCE)HY.1943-7900.0000734
[20]	Bruneau N, Bonneton P, Castelle B, et al. Modeling rip current circulations and vorticity in a high-energy mesotidal-macrotidal environment[J]. Journal of Geophysical Research: Oceans, 2011, 116(C7): C07026.
[21]	Scott T, Austin M, Masselink G, et al. Dynamics of rip currents associated with groynes——field measurements, modelling and implications for beach safety[J]. Coastal Engineering, 2016, 107: 53−69. doi: 10.1016/j.coastaleng.2015.09.013
[22]	Aagaard T, Greenwood B, Nielsen J. Mean currents and sediment transport in a rip channel[J]. Marine Geology, 1997, 140(1/2): 25−45.
[23]	Brander R W, Short A D. Morphodynamics of a large-scale rip current system at Muriwai Beach, New Zealand[J]. Marine Geology, 2000, 165(1/4): 27−39.
[24]	Haller M C, Dalrymple R A, Svendsen I A. Experimental study of nearshore dynamics on a barred beach with rip channels[J]. Journal of Geophysical Research: Oceans, 2002, 107(C6): 14-1−14-21.
[25]	闫圣. 缓坡海岸沿岸流和边界控制裂流系统特征研究[D]. 大连: 大连理工大学, 2021. Yan Sheng. Study on the features of longshore currents on mild beaches and boundary rip current systems[D]. Dalian: Dalian University of Technology, 2021.
[26]	MacMahan J H, Thornton E B, Stanton T P, et al. RIPEX: observations of a rip current system[J]. Marine Geology, 2005, 218(1/4): 113−134.
