Metallogenic mechanism of the Zhaiying Cryogenian marine manganese-bearing formation in South China
-
摘要: 寨英海相碳酸盐型锰矿床是华南地区南华裂谷盆地大塘坡组黑色页岩型海相含锰建造的重要组成部分。与盆地其它矿区大塘坡组锰矿石产状不同，寨英部分块状锰矿石含有独特的气泡构造。为探讨寨英海相含锰建造的成因机制，本文通过对寨英锰矿区野外地质调查取样，利用岩石学和地球化学方法对气泡状锰矿石、块状锰矿石及围岩黑色页岩全岩样品的主量元素含量、微量元素含量、有机碳同位素和碳酸盐碳稳定同位素组成等开展了研究。主要结果如下：1）寨英锰矿石呈轻微的“帽式”稀土元素PAAS标准化配分模式。锰矿石明显的正Ce异常和氧化还原敏感元素U、V亏损的特征，表明锰矿沉积环境为氧化状态，锰最初以氧化物沉淀，与现代大洋海底水成型锰结核（壳）沉淀机制类似。围岩黑色页岩缺乏明显的正Ce异常并含有较多黄铁矿，指示其沉积环境为缺氧状态。2）锰矿石富集轻碳同位素δ13Ccarb（−10.60～−8.53‰，平均−9.45‰），同地史时期大多数黑色页岩型海相碳酸锰矿床成矿过程类似，即锰氧化物作为电子受体氧化有机质为碳酸锰沉淀提供了主要碳源HCO3−，且可能由于更多有机质参与了成矿，寨英较其它矿区大塘坡组锰矿石δ13Ccarb（−8～−6‰）偏负。3）锰矿石正Eu异常及含有较少陆源碎屑主要构成元素（Al、Ti）的特征，表明锰质主要来源于热液。文章表明，寨英与南华裂谷盆地其它矿区大塘坡组锰矿石具有非常相似的沉积和成矿过程。Abstract: The Zhaiying carbonate-type Mn deposit belongs to the black shale hosted marine manganese(Mn)-bearing formations within the Datangpo Formation in the Nanhua Rift Basin in South China. Unlike other Mn deposits of the Datangpo Formation, parts of the Mn ores in the Zhaiying deposit bear unique bubble structures. To elucidate the metallogenic mechanism of the Zhaiying marine Mn-bearing formation, in this study, petrographic and whole-rock geochemical analyses, including measurements of major and trace elements, organic carbon isotopes, and carbonate carbon stable isotopes, were conducted using the bubble and massive Mn ores as well as host rocks (black shales). The main results are as follows: 1) The PAAS-normalized rare-earth element pattern of the Zhaiying Mn ores exhibits a “hat-shaped” plot. The Mn ores exhibit obvious positive Ce anomalies and are depleted in U and V, implying that the primary depositional environment of the Mn ores was oxidative. Primary Mn oxidizing precipitation has a mechanism similar to marine hydrogenous Mn–Fe nodules and crusts. However, the obvious absence of Ce anomalies and enrichment of pyrites in the host rocks indicate an anoxic depositional environment. 2) The Mn ores are enriched in light δ13Ccarb (−8.53‰ to −10.60‰, averaging at −9.45‰), similar to those belonging to major carbonate-type Mn deposits during geological time. This indicates that primary Mn oxides, as electron acceptors, oxidized organic matter to provide HCO3− for Mn carbonate formation. Moreover, the Zhaiying Mn ores have more negative δ13Ccarb values than other Mn deposits (δ13Ccarb: −8‰ to −6‰) of the Datangpo Formation owing to the greater contribution of carbon from organic matter. 3) The Mn ores have positive Eu anomalies and minor amounts of terrigenous detrital elements (Al, Ti), indicating that the Mn source was hydrothermal. In summary, the results show that the Zhaiying Mn deposit has deposition and mineralizing processes similar to other Mn deposits of the Datangpo Formation in the Nanhua Rift Basin.
-
图 2 （a）南华裂谷盆地（I级）中武陵次级裂谷盆地（II级）海相含锰建造的分布位置；（b）寨英海相含锰建造地层剖面特征以及锰矿石和围岩地层位置。（修改自文献[18, 19]）
Fig. 2 (a) The location map of sedimentary Mn-bearing formations in Wuling Rift Basin (level II) in Nanhua Rift Basin (level I); (b) The stratigraphic profile and lithology of the Zhaiying Mn mine and the positions of Mn ores and host rocks. (adapted from references [18] and [19])
图 3 寨英矿区锰矿石及围岩黑色页岩的手标本照片。（a-c）气泡状锰矿石；（d-e）块状锰矿石；（f）黑色页岩
Fig. 3 Hand specimens of Mn ores and host rocks of the Zhaiying Mn mine. (a-c) Massive Mn ores samples with bubble structures (bubble Mn ores); (d-e) Massive Mn ore samples; (f) A black shale sample.
图 4 寨英矿区气泡状锰矿石切面3 mm直径微钻取样
Fig. 4 Sampling points by 3-mm-diameter microdrilling of a Mn ore sample with bubble structure collected from the Zhaiying Mn mine
图 5 寨英矿区大塘坡组气泡状锰矿石、块状锰矿石及围岩黑色页岩部分主量元素与锰元素的相对含量（红色实心圆圈代表气泡状锰矿石、蓝色方块代表块状锰矿石、黑色三角代表黑色页岩。以下图中寨英矿区样品的数据标记均与本图相同。）
Fig. 5 Relative contents of several major elements and Mn content for bubble, massive Mn ores and host rocks (black shales) of Zhaiying Mine. (Note: The red circle represents bubble Mn ores, the bule square represents massive Mn ores, and the black triangle represents host rocks in this and the following figures)
图 6 寨英矿区气泡状锰矿石、块状锰矿石及围岩微量和稀土元素PAAS标准化配分曲线（注：阴影部分为南华裂谷盆地其它矿区大塘坡组锰矿石及围岩黑色页岩微量和稀土元素PAAS标准化配分曲线，其数据来源于文献[19, 24]）
Fig. 6 The PAAS-normalized trace elements and REY patterns of bubble, massive Mn ores and host rocks of Zhaiying Mine (The shadow areas indicate the PAAS-normalized trace elements and REY patterns of Mn ores and host rocks from the Datangpo Formation of other Mn mines in the Nanhua Rift Basin. Data is from references [19] and [24]).
图 7 （a）气泡状锰矿石含锰矿物及气泡构造的背散射电子图像；（b）气泡构造环边的二次电子图像；（c）块状锰矿石含锰矿物的背散射电子图像；（d）黑色页岩的背散射电子图像
Fig. 7 (a) A back scattered electron (BSE) image of Mn-bearing minerals and the bubble structure; (b) A secondary electron (SE) image of the rim of a bubble structure; (c) A BSE image of Mn-bearing minerals of a massive Mn ore; (d) A BSE image of a black shale sample.
图 8 （a）寨英矿区气泡状、块状锰矿石及围岩黑色页岩的Ce特征及其与Mn含量相关性。（b）海底典型冷泉碳酸盐岩稀土元素PAAS标准化配分曲线。其数据来源于文献：南海北部陆坡[31]；东海冲绳海槽[32]；墨西哥湾布什山[33]；南海琼东南盆地[34]。
Fig. 8 (a) The Ce (a) anomalies and the correlations vs. Mn contents for bubble, massive Mn ores and host rocks collected from the Zhaiying Mn Mine. (b) REY patterns of several typical marine cold-seep carbonates. Data are from references: Continental slope of the northern South China Sea[31]; East China Sea[32]; Bush Hill, Gulf of Mexico[33]; Qiongdongnan Basin, South China[34].
图 9 寨英矿区气泡状、块状锰矿石样品投射在Bau等[26]提出的现代大洋海底水成、成岩和热液型铁锰沉积基于稀土元素的识别图谱（注：虚线是其它矿区大塘坡组锰矿石投射范围，数据来源于文献[19]。SN表示样品稀土元素经澳大利亚后太古代页岩PAAS标准化。）。
Fig. 9 The distribution of bubble and massive Mn ores on the discrimination diagrams for hydrogenetic, diagenetic, and hydrothermal Mn-Fe deposits in modern marine proposed by Bau et al. [26]. (The dash areas indicate the related data of Mn ores from the Datangpo Formation of other Mn mines in the Nanhua Rift Basin. Data are from reference [19]. SN represents the rare earth element contents of the samples were normalized against that of Post-Archaean Australian Average Shale (PAAS).)
图 10 寨英矿区气泡状、块状锰矿石δ13Ccarb与Mn含量的相关性
Fig. 10 The correlations between δ13Ccarb and Mn contents for bubble, massive Mn ores collected from the Zhaiying Mn Mine.
图 11 （a）基于δ13C和δD特征的不同成因甲烷的分类图谱（修改自文献[65]）。（b）寨英矿区气泡状、块状锰矿石和围岩的Eu特征及其与Mn含量相关性。
Fig. 11 (a) A diagram for classification of bacterial and thermogenic methane by the combination of δ13C and δD information (adapted from [65]). (b) The Eu features and its correlation with Mn contents for bubble, massive Mn ores and host rocks collected from the Zhaiying Mn Mine.
表 1 寨英矿区大塘坡组气泡状锰矿石、块状锰矿石和黑色页岩样品的主量元素含量（wt.%）
Tab. 1 Major element contents of bubble, massive Mn ores and black shales collected from the Datangpo Formation of Zhaiying Mn mine (wt.%)
样品号 岩石类型 TMn TFe P CaO MgO Na2O Al2O3 SiO2 TiO2 K2O S Fe/Mn Al/(Al+Fe+Mn） B-1 气泡状锰矿石 28.33 1.40 0.069 9.91 4.53 0.056 1.48 6.05 0.176 0.403 0.123 0.0494 0.0256 B-2 气泡状锰矿石 26.71 1.14 0.639 9.04 4.01 0.063 1.28 12.83 0.169 0.221 0.187 0.0427 0.0237 B-3 气泡状锰矿石 28.14 1.27 0.227 8.26 4.32 0.064 1.17 11.15 0.155 0.206 0.197 0.0451 0.0206 B-4 气泡状锰矿石 28.19 1.52 0.084 7.42 4.00 0.073 2.48 11.13 0.164 0.530 0.191 0.0539 0.0423 B-5 气泡状锰矿石 28.44 1.55 0.071 9.90 4.79 0.060 1.52 5.88 0.143 0.404 0.113 0.0545 0.0261 B-6 气泡状锰矿石 27.01 1.30 0.070 11.22 4.62 0.057 1.47 6.84 0.167 0.419 0.125 0.0481 0.0267 B-7 气泡状锰矿石 28.26 1.29 0.083 6.89 3.70 0.065 2.56 10.60 0.180 0.676 0.137 0.0456 0.0439 B-8 气泡状锰矿石 28.34 1.42 0.067 9.66 4.33 0.064 1.62 7.12 0.160 0.415 0.119 0.0501 0.0280 B-9 气泡状锰矿石 27.96 1.39 0.068 10.60 4.41 0.065 1.39 7.07 0.103 0.338 0.122 0.0497 0.0245 B-10 气泡状锰矿石 30.21 1.53 0.094 7.34 3.94 0.064 2.26 7.72 0.173 0.549 0.144 0.0506 0.0363 B-11 气泡状锰矿石 27.73 1.35 0.067 10.36 4.35 0.058 1.61 6.97 0.170 0.423 0.106 0.0487 0.0284 B-12 气泡状锰矿石 27.81 1.39 0.070 11.08 4.51 0.057 1.33 5.95 0.145 0.354 0.108 0.0500 0.0235 M-1 块状锰矿石 27.55 1.62 0.113 5.89 4.68 0.068 3.00 11.82 0.197 0.742 0.334 0.0588 0.0516 M-2 块状锰矿石 30.32 1.58 0.080 9.49 3.77 0.051 1.53 5.78 0.109 0.508 0.149 0.0521 0.0248 M-3 块状锰矿石 20.70 2.02 0.234 10.47 3.20 0.063 4.66 16.78 0.277 1.210 1.15 0.0976 0.0979 M-4 块状锰矿石 29.02 1.16 0.080 9.44 4.43 0.054 0.88 4.76 0.162 0.254 0.090 0.0400 0.0152 M-5 块状锰矿石 28.86 1.45 0.097 6.74 5.14 0.057 1.11 6.43 0.209 0.321 0.218 0.0502 0.0190 C-2 块状锰矿石 17.45 4.05 0.176 6.86 2.45 0.061 6.21 23.38 0.377 1.589 1.81 0.2321 0.1327 C-1 黑色页岩 1.11 4.09 0.069 1.55 1.22 1.88 15.24 58.20 0.755 3.80 3.04 3.69 0.6080 C-3 黑色页岩 0.130 4.84 0.063 0.37 0.84 2.50 15.72 59.86 0.719 3.58 2.23 37.20 0.6260 C-4 黑色页岩 0.152 5.53 0.122 0.50 1.17 1.81 21.12 47.61 0.949 5.76 1.02 36.40 0.6631 C-5 黑色页岩 0.275 4.12 0.084 0.61 0.94 2.78 16.23 59.09 0.738 3.69 2.46 14.98 0.6616 C-6 黑色页岩 0.636 3.54 0.065 0.95 1.02 2.22 14.44 63.38 0.615 3.28 3.14 5.57 0.6467 C-7 黑色页岩 0.193 5.29 0.116 0.54 1.07 1.90 19.44 50.80 0.929 5.12 1.36 27.42 0.6525 C-8 黑色页岩 0.161 4.16 0.115 0.51 0.91 2.88 15.99 58.34 0.802 3.40 1.13 25.83 0.6619 C-9 黑色页岩 2.47 3.60 0.101 1.85 1.22 2.54 14.60 57.13 0.694 3.18 2.34 1.46 0.5604
下载: 导出CSV
表 2 寨英矿区大塘坡组气泡状锰矿石、块状锰矿石和黑色页岩样品的微量元素含量（ppm）
Tab. 2 Trace element contents of bubble, massive Mn ores and black shales collected from the Datangpo Formation of Zhaiying Mn mine (ppm)
样品号 岩石类型 V Cr Co Ni Cu Zn Rb Sr Zr Mo Ba Pb Th U B-1 气泡状锰矿石 47.2 5.79 6.16 5.78 3.76 28.2 15.6 404 22.6 1.31 187 1.43 1.67 0.605 B-2 气泡状锰矿石 39.0 7.73 11.3 7.91 6.75 29.5 9.06 404 79.7 0.347 149 0.914 1.54 0.784 B-3 气泡状锰矿石 38.5 8.11 13.1 8.80 7.28 46.8 8.42 370 54.2 0.35 156 0.988 1.57 0.823 B-4 气泡状锰矿石 52.8 8.82 8.59 6.55 8.00 33.6 19.8 346 35.1 0.408 182 1.96 2.73 0.822 B-5 气泡状锰矿石 48.3 5.77 6.15 5.68 3.77 25.2 15.2 430 21.6 0.53 188 1.39 1.76 0.378 B-6 气泡状锰矿石 55.2 6.95 6.12 6.49 4.14 57.8 15.9 441 25.3 0.27 158 1.01 1.85 0.374 B-7 气泡状锰矿石 60.4 8.03 6.88 9.34 6.96 33.3 24.8 319 31.2 0.798 211 1.27 2.16 0.56 B-8 气泡状锰矿石 48.1 6.00 6.25 5.73 3.82 21.7 16.3 423 24.3 0.836 192 1.50 1.85 0.327 B-9 气泡状锰矿石 42.2 5.48 5.63 5.35 4.12 24.3 13.3 456 20.5 0.197 168 1.16 1.61 0.354 B-10 气泡状锰矿石 48.9 9.2 6.52 6.98 5.37 26.2 20.6 310 30.4 1.30 221 1.14 2.30 0.578 B-11 气泡状锰矿石 50.5 7.00 5.80 5.72 3.78 20.6 16.3 426 23.4 0.251 186 1.10 1.75 0.347 B-12 气泡状锰矿石 43.1 4.93 5.76 5.47 3.75 30.4 13.8 449 19.1 0.17 167 1.36 1.52 0.259 M-1 块状锰矿石 46.3 10.5 18.2 15.9 17.10 30.3 28.5 265 55.0 0.57 280 7.39 3.37 0.663 M-2 块状锰矿石 43.1 7.62 7.83 8.78 3.810 17.2 19.1 688 25.5 0.287 199 0.738 1.68 0.699 M-3 块状锰矿石 62.0 16.2 36.4 30.4 39.20 46.4 44.5 333 86.1 1.25 339 16.00 5.07 1.25 M-4 块状锰矿石 36.5 5.28 8.20 12.3 4.00 34.5 10.3 348 20.6 0.641 199 0.439 1.27 0.297 M-5 块状锰矿石 50.1 6.28 30.1 35.2 11.20 39.5 13.5 315 25.6 1.94 204 2.60 1.54 1.92 C-2 块状锰矿石 81.5 24.2 44.4 76.7 86.10 92.0 57.4 266 118 3.11 466 30.40 7.41 1.74 C-1 黑色页岩 180 49.6 27.8 82.6 89.7 110 147 142 246 17 864 28.1 13.0 3.08 C-3 黑色页岩 194 54.1 48.1 107 134 145 143 118 266 27 805 35.7 16.5 3.91 C-4 黑色页岩 301 68.8 62.7 121 155 96.1 214 110 323 74.3 1170 40.3 19.1 4.20 C-5 黑色页岩 189 48.4 42.5 94.5 127 97.1 138 97 245 39.0 821 35.8 13.9 3.25 C-6 黑色页岩 155 41.2 34.5 63.0 78.1 96.3 128 103 204 29.8 739 28.0 13.4 3.23 C-7 黑色页岩 261 61.6 51.5 109 152 84.3 156 92 367 24.3 967 30.4 16.2 3.41 C-8 黑色页岩 234 56.1 48.1 95.0 116 123 145 118 283 29.2 697 27.6 16.5 3.87 C-9 黑色页岩 188 48.1 46.0 72.4 101 125 118 132 132 52.7 678 27.7 12.7 2.83
下载: 导出CSV
表 3 寨英矿区大塘坡组气泡状锰矿石、块状锰矿石和黑色页岩样品的稀土元素含量（ppm）
Tab. 3 Rare earth element contents of bubble, massive Mn ores and black shales collected from the Datangpo Formation of Zhaiying Mn mine (ppm)
样品号 岩石类型 La Ce Pr Nd Sm Eu Gd Tb Dy Ho Er Tm Yb Lu Y Ce/Ce* Eu/Eu* B-1 气泡状锰矿石 16.1 50.6 4.01 16.4 3.43 1.02 3.47 0.583 3.57 0.746 2.13 0.317 1.78 0.251 19.9 1.4520 1.3862 B-2 气泡状锰矿石 20.2 66.4 5.87 24.6 4.93 1.55 4.70 0.734 4.20 0.838 2.31 0.335 1.87 0.271 23.3 1.3978 1.5132 B-3 气泡状锰矿石 18.9 58.0 4.85 19.6 3.99 1.22 3.85 0.633 3.68 0.757 2.12 0.314 1.75 0.248 21.4 1.3958 1.4622 B-4 气泡状锰矿石 19.7 59.0 4.77 19.0 3.95 1.03 3.76 0.63 3.71 0.776 2.22 0.334 1.9 0.265 21.3 1.4039 1.2560 B-5 气泡状锰矿石 18.7 58.1 4.42 17.6 3.57 1.07 3.54 0.598 3.59 0.755 2.16 0.324 1.82 0.257 20.3 1.4744 1.4124 B-6 气泡状锰矿石 20.3 60.1 4.79 19.0 3.87 1.11 3.80 0.628 3.71 0.771 2.18 0.328 1.85 0.260 21.0 1.4062 1.3588 B-7 气泡状锰矿石 15.8 47.8 4.07 16.8 3.72 0.993 3.74 0.641 3.87 0.800 2.28 0.339 1.89 0.264 21.9 1.3733 1.2485 B-8 气泡状锰矿石 18.3 55.7 4.38 17.5 3.60 1.07 3.60 0.608 3.64 0.761 2.19 0.325 1.81 0.256 20.6 1.4352 1.3943 B-9 气泡状锰矿石 17.2 53.3 4.17 16.7 3.48 1.1 3.54 0.598 3.59 0.750 2.14 0.317 1.78 0.251 20.5 1.4517 1.4690 B-10 气泡状锰矿石 18.7 53.3 4.41 17.7 3.79 1.04 3.71 0.620 3.62 0.727 2.03 0.297 1.67 0.235 20.2 1.3541 1.3022 B-11 气泡状锰矿石 15.5 48.5 3.81 15.6 3.33 1.01 3.38 0.586 3.53 0.740 2.13 0.320 1.78 0.254 20.2 1.4555 1.4113 B-12 气泡状锰矿石 16.5 52.0 4.05 16.4 3.40 1.08 3.51 0.603 3.62 0.763 2.17 0.321 1.79 0.253 20.5 1.4670 1.4643 M-1 块状锰矿石 25.9 78.9 6.42 25.1 5.07 1.38 4.92 0.826 4.86 1.01 2.87 0.427 2.40 0.338 27.0 1.4109 1.2977 M-2 块状锰矿石 17.7 51.5 4.18 16.5 3.31 0.917 3.24 0.561 3.34 0.699 1.97 0.294 1.62 0.226 18.5 1.3814 1.3147 M-3 块状锰矿石 32.5 80.5 7.76 30.3 5.91 1.54 5.55 0.905 5.30 1.10 3.14 0.465 2.70 0.387 32.2 1.1694 1.2642 M-4 块状锰矿石 18.1 53.8 4.72 19.0 4.02 1.16 4.20 0.732 4.38 0.908 2.52 0.366 1.97 0.274 23.7 1.3405 1.3214 M-5 块状锰矿石 16.6 51.8 4.42 18.0 3.80 1.21 3.90 0.668 4.01 0.834 2.32 0.338 1.83 0.252 22.0 1.3918 1.4726 C-2 块状锰矿石 45.5 110.0 11.2 44.7 9.45 2.08 8.92 1.430 8.32 1.69 4.68 0.689 4.00 0.583 48.4 1.1237 1.0650 C-1 黑色页岩 41.3 86.4 9.32 34.1 5.83 1.02 5.39 0.925 5.73 1.23 3.60 0.566 3.70 0.599 35.6 1.0160 0.8558 C-3 黑色页岩 47.2 98.5 11.2 41.7 7.61 1.25 6.79 1.10 6.54 1.32 3.78 0.583 3.84 0.624 38.1 0.9884 0.8185 C-4 黑色页岩 50.9 111.0 12 44.3 7.62 1.25 6.71 1.13 6.96 1.49 4.40 0.696 4.62 0.758 42.7 1.0362 0.8229 C-5 黑色页岩 26.8 55.9 6.63 25.3 5.05 0.895 5.07 0.864 5.42 1.17 3.46 0.547 3.59 0.584 33.0 0.9670 0.8296 C-6 黑色页岩 53.0 116.0 12 43.0 6.68 1.25 5.35 0.869 5.10 1.07 3.17 0.497 3.24 0.518 30.9 1.0612 0.9843 C-7 黑色页岩 40.8 80.1 9.7 36.0 6.31 1.07 5.72 0.946 5.92 1.28 3.79 0.601 4.02 0.659 36.2 0.9289 0.8380 C-8 黑色页岩 42.3 88.5 9.87 36.7 6.87 1.25 6.33 1.02 6.21 1.29 3.77 0.591 3.98 0.649 37.9 0.9993 0.8916 C-9 黑色页岩 46.1 104.0 10.8 39.4 7.38 1.29 5.80 0.82 4.29 0.847 2.42 0.401 2.68 0.419 22.4 1.0753 0.9280
下载: 导出CSV
表 4 寨英矿区大塘坡组气泡状、块状锰矿石和黑色页岩全岩碳酸盐稳定碳和有机碳同位素组成
Tab. 4 Whole rock δ13Ccarb and δ13Corg values of bubble, massive Mn ores and black shales collected from the Datangpo Formation of Zhaiying Mn mine
样品号 岩石类型 碳酸盐稳定碳同位素
δ13Ccarb V-PDB (‰)有机碳同位素
δ13Corg V-PDB (‰)B1 气泡状锰矿石 -8.60 -33.56 B2 气泡状锰矿石 -9.02 -33.37 B3 气泡状锰矿石 -9.34 -33.76 B4 气泡状锰矿石 -10.28 -33.04 B5 气泡状锰矿石 -8.83 -32.08 B6 气泡状锰矿石 -9.29 -33.34 B7 气泡状锰矿石 -10.35 -33.86 B8 气泡状锰矿石 -8.80 -32.68 B9 气泡状锰矿石 -9.22 -33.49 B10 气泡状锰矿石 -10.60 -33.84 B11 气泡状锰矿石 -8.53 -32.86 B12 气泡状锰矿石 -9.21 -33.04 M-1 块状锰矿石 -9.76 -32.04 M-2 块状锰矿石 -10.58 -33.08 M-3 块状锰矿石 -9.20 -32.14 M-4 块状锰矿石 -9.60 -33.17 M-5 块状锰矿石 -10.00 -31.09 C-2 块状锰矿石 -8.86 -32.49 C-1 黑色页岩 -8.36 -33.65 C-3 黑色页岩 -8.48 -33.43 C-4 黑色页岩 -9.86 -33.04 C-5 黑色页岩 -9.23 -33.28 C-6 黑色页岩 -9.44 -34.04 C-7 黑色页岩 -8.77 -33.09 C-8 黑色页岩 -9.05 -32.76 C-9 黑色页岩 -6.99 -33.08
下载: 导出CSV
表 5 寨英矿区气泡状锰矿石微钻取样样品的碳酸盐稳定碳同位素组成
Tab. 5 δ13Ccarb values of microsamples collected at sampling points by microdrilling form a bubble Mn ore collected from the Datangpo Formation of Zhaiying Mn mine
样品号 样品类型 碳酸盐稳定碳同位素
δ13CV-PDB (‰)1 气泡状锰矿石 -11.60 2 气泡状锰矿石 -11.37 3 气泡状锰矿石 -11.76 4 气泡状锰矿石 -11.79 5 气泡状锰矿石 -10.99 6 气泡状锰矿石 -11.54 7 气泡状锰矿石 -11.44 8 气泡状锰矿石 -11.46 9 气泡状锰矿石 -11.47 10 气泡状锰矿石 -11.61 11 气泡状锰矿石 -12.09 12 气泡状锰矿石 -11.16 13 气泡状锰矿石 -11.13 14 气泡状锰矿石 -11.36 15 气泡状锰矿石 -11.28
下载: 导出CSV
-
