Monte-Carlo模拟与经验路径模型预测台风极值风速的对比

郭云霞; 侯一筠; 齐鹏

doi:10.3969/j.issn.0253-4193.2020.07.006

Monte-Carlo模拟与经验路径模型预测台风极值风速的对比

doi: 10.3969/j.issn.0253-4193.2020.07.006

郭云霞^{1, 2, 4,},
侯一筠^{1, 2, 3, 4, ,},
齐鹏^{1, 3, 4}

1.
中国科学院海洋研究所，山东青岛 266071
2.
中国科学院大学，北京 100049
3.
青岛海洋科学与技术试点国家实验室海洋与气候动力学实验室，山东青岛 266237
4.
中国科学院海洋大科学研究中心，山东青岛 266071

基金项目: 国家重点研发计划项目（2018YFC1407003，2016YFC1402000）；国家自然科学基金（U1606402，41421005）。

详细信息

作者简介:
郭云霞(1986-)，女，山东省泰安市人，博士生，从事海洋灾害研究。E-mail：guoyunxia14@mails.ucas.edu.cn

通讯作者:
侯一筠，男，研究员，主要从事物理海洋学研究。E-mail：yjhou@qdio.ac.cn

中图分类号: P444
计量
- 文章访问数: 603
- HTML全文浏览量: 129
- PDF下载量: 80
- 被引次数: 0
出版历程
- 收稿日期: 2019-07-08
- 修回日期: 2019-12-26
- 网络出版日期: 2020-11-18
- 刊出日期: 2020-07-25

Comparison of extreme wind speeds predicted by Monte-Carlo simulation and empirical track model

Guo Yunxia^{1, 2, 4
,},
Hou Yijun^{1, 2, 3, 4
, ,},
Qi Peng^{1, 3, 4}

1.
Institute of Oceanology, Chinese Academy of Sciences, Qingdao 266071, China
2.
University of Chinese Academy of Sciences, Beijing 100049, China
3.
Laboratory for Ocean and Climate Dynamics, Pilot National Laboratory for Marine Science and Technology (Qingdao), Qingdao 266237, China
4.
Center for Ocean Mega-Science, Chinese Academy of Sciences, Qingdao 266071, China

摘要

摘要: 台风是我国东南沿海区域每年发生的严重自然灾害之一。本文分别采用传统的Monte-Carlo模拟方法以及较为先进的经验路径模拟方法预测中国东南沿海区域台风的极值风速(10 m高度处10 min平均值)，并对两种方法的预测结果进行了对比。本文将东南海岸线向内陆扩展约200 km的区域划分为0.25°×0.25°的网格，以每个网格点作为研究点。首先采用Monte-Carlo模拟方法产生每个研究点1 000年间的虚拟台风事件。然后采用经验路径模型方法构建了西北太平洋1 000年的热带气旋事件集，采用模拟圆方法从中提取对各个研究站点有影响的台风事件。接着采用Yan Meng风场模型计算每个研究点台风的最大风速，构成极值风速序列。最后采用极值分布模型预测每个研究点不同重现期的极值风速，并对两种不同方法预测的结果进行了对比。研究发现在研究区域的内陆侧经验路径方法预测的风速略高于Monte-Carlo模拟方法预测的结果，而在海岸沿线一带经验路径方法预测的结果略低，这主要是由两种方法构造的虚拟台风的中心压强存在差异以及模型本身的不确定性造成的。本文的研究结果可以为防灾减灾系统提供有益的参考。
- 台风 /
- Monte-Carlo模拟 /
- 经验路径模型 /
- 风场模型 /
- 极值风速
Abstract: Typhoon is one of the most serious natural disasters in southeast coastal region of China. In this paper, the traditional Monte-Carlo simulation and the advanced empirical track model are respectively used to predict the extreme wind speed (10-min mean at 10 m height) of typhoons in the southeast coastal region of China, and the prediction results of two methods are compared. An area extending 200 km inland from the coastline is divided into 0.25°×0.25° grid cells and each grid is taken as the research point. Firstly, the Monte-Carlo method is used to generate virtual typhoons of 1 000-year for each research point. Then, we use the empirical track model to construct virtual typhoons of 1 000-year in the Northwest Pacific Ocean, from which typhoon events affecting each research site are extracted by using the simulation circle method. Next, the Yan Meng wind field model is used to calculate the wind speed of the extracted typhoons, from which samples of maximum wind speed can be derived. Finally, the extreme wind speed of different return periods for each research point is predicted by the extreme value distribution. Through comparison, we find that in some inland areas, the predicted wind speeds by empirical track model are slightly higher than those by Monte-Carlo method, and in most coastal areas the opposite is true. This is mainly caused by the difference of the central pressure of the virtual typhoons constructed by two methods and the uncertainty of the model itself. The research results of this paper can provide useful reference for the disaster prevention and mitigation system.
- typhoon /
- Monte-Carlo simulation /
- empirical track model /
- wind field model /
- extreme wind speed

HTML全文

图 1 虚拟台风过程示意图

Fig. 1 A schematic graph for simulation of the virtual typhoon

下载: 全尺寸图片幻灯片

图 2 CMA数据中台风的起始点以及西北太平洋区域5°×5°的网格

Fig. 2 Spatial distribution of genesis based on the CMA best-track dataset and the grid cell of 5°×5° in the Northwest Pacific Ocean

下载: 全尺寸图片幻灯片

图 3 观测的台风初始移动速度（a）与移动方向（b）的概率分布拟合

Fig. 3 Modeled and observed statistical distributions of translation speed (a) and storm heading (b)

下载: 全尺寸图片幻灯片

图 4 对于东向与西向运动的台风拟合的公式（11）中的系数a_i和ε_c的分布

Fig. 4 Illustration of regression coefficients a_i and ε_c in Eq.(11) for easterly and westerly headed storms

下载: 全尺寸图片幻灯片

图 5 研究站点（黑色星号）、用于验证经验路径模型的站点（蓝色方框）以及8个沿岸城市（红点）的位置分布

Fig. 5 Locations of research points (black asterisks), stations for validation of empirical track model (blue squares) and 8 coastal cities (red dots)

下载: 全尺寸图片幻灯片

图 6 沿岸46个站点虚拟与观测的台风关键参数的对比

Fig. 6 Comparison of key parameters of simulated and observed typhoons at 46 coastal stations

下载: 全尺寸图片幻灯片

图 7 不同研究点的粗糙度

Fig. 7 The roughness length for each site of interest

下载: 全尺寸图片幻灯片

图 8 本文预测的8个沿岸城市极值风速与Li和Hong^[33]以及规范值^[45]的对比

a.50年一遇；b.100年一遇

Fig. 8 Comparison of extreme wind speeds of 8 coastal cities between this study, Li and Hong^[33] and the design code^[45]

a. 50-year return period; b. 100-year return period

下载: 全尺寸图片幻灯片

图 9 采用Monte-Carlo方法以及经验分布预测的50年重现期的极值风速（a）以及经验路径方法与Monte-Carlo方法预测结果的差值(b)

Fig. 9 Extreme wind speeds for 50-year return period by Monte-Carlo simulation and empirical distribution (a) and the wind speed difference between empirical track model and Monte-Carlo simulation (b)

下载: 全尺寸图片幻灯片

图 10 采用Monte-Carlo方法以及经验分布预测的100年重现期的极值风速（a）以及经验路径方法与Monte-Carlo方法预测结果的差值（b）

Fig. 10 Extreme wind speeds for 100-year return period by Monte-Carlo simulation and empirical distribution (a) and the wind speed difference between empirical track model and Monte-Carlo simulation (b)

下载: 全尺寸图片幻灯片

图 11 采用Monte-Carlo方法以及威布尔分布预测的50年重现期的极值风速（a）以及经验路径方法与Monte-Carlo方法预测结果的差值（b）

Fig. 11 Extreme wind speeds for 50-year return period by Monte-Carlo simulation and Weibull distribution (a) and the wind speed difference between empirical track model and Monte-Carlo simulation (b)

下载: 全尺寸图片幻灯片

图 12 采用Monte-Carlo方法以及耿贝尔分布预测的50年重现期的极值风速（a）以及经验路径方法与Monte-Carlo方法预测结果的差值（b）

Fig. 12 Extreme wind speeds for 50-year return period by Monte-Carlo simulation and Gumbel distribution (a) and the wind speed difference between empirical track model and Monte-Carlo simulation (b)

下载: 全尺寸图片幻灯片

图 13 采用Monte-Carlo方法以及经验路径方法得到的579个研究站点的中心压差的平均值的差值（a）以及图13a与图9b正负号一致的站点（红点）与不一致的站点（蓝点）（b）

Fig. 13 The difference of the mean value of the central pressure difference for 579 research stations between Monte-Carlo simulation and empirical track method (a), and stations with the same (red dots) and different (blue dots) signs in Fig.13a and Fig.9b (b)

下载: 全尺寸图片幻灯片

表 1 不同地形地貌的粗糙度

Tab. 1 Roughness length of different geomorphology

地形等级	下垫面特征	粗糙度/m
I	海面、泥滩、冰雪覆盖的平原，无障碍海岸地区等	0.000 5～0.003
II	平坦开阔的田野、乡村及丛林等（气象学标准）	0.003～0.2
III	丘陵和房屋比较稀疏的乡镇及城市郊区	0.2～1.0
IV	密集建筑群的城市	1.0～2.0
V	密集建筑群且房屋较高的城市	2.0～4.0

下载: 导出CSV

表 2 公式(2)的衰减常数a

Tab. 2 Decay constant a in Eq. (2)

区域	N	$a = {a_0} + {a_1}\Delta {p_0} + \varepsilon $
区域	N	a₀	a₁	R²	σ_ε
区域1	36	0.0078	0.00075	0.0928	0.0198
区域2	66	0.0161	0.00055	0.0946	0.0203
区域3	159	0.0137	0.0012	0.2139	0.0247
区域4	82	−0.0035	0.0019	0.4768	0.0216
区域5	40	−0.0026	0.00052	0.5321	0.0116
注：N代表各个区域中用于回归分析的样本个数，R²是回归分析的相关系数，σ_ε是误差项的标准差。

下载: 导出CSV
