基于卷积神经网络和数据融合的筏式养殖区提取

李龙坤; 蔡玉林; 徐慧宇; 刘照磊; 王思超; 高洪振

doi:10.12284/hyxb2023147

基于卷积神经网络和数据融合的筏式养殖区提取

doi: 10.12284/hyxb2023147

山东科技大学测绘与空间信息学院3S工程技术研究中心，山东青岛 266590

基金项目: 山东省自然科学基金（ZR2022MD002）

详细信息

作者简介:
李龙坤（1997-），男，山东省济南市人，主要从事资源与环境遥感研究。E-mail: 1475013073@qq.com

通讯作者:
蔡玉林，副教授，主要从事遥感图像处理和信息提取以及遥感在资源环境中的应用研究。E-mail: caiyl@sdust.edu.cn

中图分类号: P751
计量
- 文章访问数: 226
- HTML全文浏览量: 59
- PDF下载量: 70
- 被引次数: 0
出版历程
- 收稿日期: 2022-10-03
- 修回日期: 2022-12-22
- 网络出版日期: 2023-04-24
- 刊出日期: 2023-08-31

Extraction of the raft aquaculture area based on convolutional neural networks and data fusion

3S Engineering and Technology Research Center, College of Geodesy and Geomatics, Shandong University of Science and Technology, Qingdao 266590, China

摘要

摘要: 准确提取海水筏式养殖区信息对于海洋资源管理和环境监测具有重要意义，但是筏式养殖区养殖筏因淹没于水中常出现数据弱信号区域的现象，导致仅凭光学影像提取精度较低。因此，本文以威海荣成湾为研究区域，通过添加通道注意力机制改进U-Net神经网络并结合高分2号光学影像光谱信息以及高分3号雷达影像纹理信息，尝试提高筏式养殖区提取精度。结果表明：（1）无论是对于单一的光学影像还是光学和雷达影像融合影像，添加通道注意力机制的U-Net神经网络预测结果总体精度都会提高，提高幅度在2.21%～4.12%之间。（2）利用改进后的U-Net神经网络处理融合数据，总体精度达到95.75%，相对于仅用高分2号影像的精度高4.3%；（3）对于弱信号区域，利用改进网络以及融合数据提取的总体精度和Kappa系数分别为91.61%和0.827 7。该方法可以对海洋筏式养殖区弱信号区域进行有效提取，能够为海洋养殖面积统计以及海洋环境检测提供技术支持。
- 筏式养殖区 /
- 弱信号区域 /
- 通道注意力机制 /
- U-Net /
- 影像融合
Abstract: Accurate extraction of marine raft aquaculture area information is of great significance for marine resource management and environmental monitoring. But the raft culture area is often submerged in water with weak data signal areas, resulting in low extraction accuracy based on optical images alone. Therefore, this paper takes Weihai Rongcheng Bay as the research area, and improves the U-Net neural network by adding channel attention mechanism to combine the spectral information of GF-2 optical image and the texture information of GF-3 radar image, trying to improve the extraction accuracy of raft aquaculture area. The results show that: （1) Whether it is a single optical image or a fusion image of optical and radar images, the overall accuracy of the prediction results of the U-Net neural network with channel attention mechanism will be improved, with an increase of 2.21%−4.12%. （2) Using the improved U-Net neural network to process the fusion data, the overall accuracy is 95.75%, which is 4.3% higher than that of only using GF-2 image. （3) For weak signal region, the overall accuracy and Kappa coefficient of extraction based on improved network and data fusion are 91.61% and 0.827 7, respectively. This method can effectively extract the weak signal area of marine raft aquaculture area, and can provide technical support for marine aquaculture area statistics and marine environment detection.
- raft aquaculture area /
- weak signal area /
- channel attention mechanism /
- U-Net /
- image fusion

HTML全文

图 1 研究区

a. 研究区所在位置；b. 高分二号卫星影像；c. 高分三号卫星影像

Fig. 1 Study area

a. Location of the study area; b. GF-2 satellite image; c. GF-3 satellite image

下载: 全尺寸图片幻灯片

图 2 局部区域融合前后影像对比

Fig. 2 Image comparison before and after local regional fusion

下载: 全尺寸图片幻灯片

图 3 采用通道注意力机制的U-Net神经网络结构

Fig. 3 U-Net neural network structure adopting channel attention mechanism

下载: 全尺寸图片幻灯片

图 4 基于全局最大池化和平均池化的SE模块

Fig. 4 SE module based on global max pooling and average pooling

下载: 全尺寸图片幻灯片

图 5 技术路线图

Fig. 5 Technology roadmap

下载: 全尺寸图片幻灯片

图 6 U-Net与SE_U-Net模型预测结果

Fig. 6 Prediction results for U-Net and SE_U-Net

下载: 全尺寸图片幻灯片

图 7 局部典型区域标签与预测结果

Fig. 7 Typical subarea labels and prediction results

下载: 全尺寸图片幻灯片

图 8 弱信号区域预测结果

a为原始影像；b为标签数据；c为GF2数据集预测结果；d为GF23S数据集预测结果；e为GF23B数据集预测结果

Fig. 8 Prediction results of weak signal areas

a: Original image; b: label image; c: prediction result of GF2 dataset; d: prediction result of GF23S dataset; e: prediction result of GF23B dataset

下载: 全尺寸图片幻灯片

表 1 混淆矩阵

Tab. 1 Confusion matrix

真实值	模型预测结果
真实值	正例	反例
正例	TP	FN
反例	FP	TN

下载: 导出CSV

表 2 U-Net与SE_U-Net模型预测结果精度评估

Tab. 2 Evaluation of the extraction result for U-Net and SE_U-Net model

模型		GF2	GF23S	GF23B
U-Net	总体精度/%	85.30	87.47	91.33
	Kappa系数	0.708 7	0.751 0	0.826 8
SE_U-Net	总体精度/%	89.42	89.68	93.71
	Kappa系数	0.788 7	0.794 3	0.874 0

下载: 导出CSV

表 3 不同数据集预测精度

Tab. 3 Prediction accuracy for different datasets

数据集	类别	召回率/ %	精确率/ %	错分率/%	漏分率/%	F1分数
GF2	背景	95.08	88.61	11.39	4.92	91.73
	养殖区	80.54	91.14	8.86	19.46	85.51
GF23S	背景	97.11	93.78	6.22	2.89	95.42
	养殖区	89.74	95.12	4.88	10.26	92.35
GF23B	背景	96.96	96.16	3.84	3.04	96.56
	养殖区	93.84	95.10	4.90	6.16	94.50

下载: 导出CSV

表 4 不同数据集预测结果精度评估

Tab. 4 Evaluation of the extraction result for different datasets

数据集	总体精度/%	Kappa系数
GF2	89.47	0.772 9
GF23S	94.27	0.877 7
GF23B	95.75	0.910 2

下载: 导出CSV

表 5 弱信号区域预测结果精度评估

Tab. 5 Evaluation of the extraction result of the weak signal areas

测试区	数据集	总体精度/%	Kappa系数
Test1	GF2	81.41	0.6334
	GF23S	84.75	0.6965
	GF23B	91.61	0.8277
Test2	GF2	89.52	0.7463
	GF23S	91.79	0.8052
	GF23B	94.30	0.8717
Test3	GF2	82.40	0.6428
	GF23S	88.18	0.7620
	GF23B	91.59	0.8309

下载: 导出CSV
