Vertical displacement loading tides and self-attraction and loading tides in the South China Sea and adjacent straits
-
摘要: 本文采用Green函数方法，基于高分辨率南海海潮模型、DTU10全球海洋潮汐模型以及Gutenberg-Bullen A地球模型计算了南海及邻近海峡的负荷潮。结果表明，M2垂向位移负荷潮振幅最大值出现在台湾海峡，其值超过18 mm；另一个极大值区出现在加里曼丹岛西北外海，其值超过14 mm。K1和O1垂向位移负荷潮振幅在南海南部最大，分别超过18 mm和14 mm；另一个极大值区出现在北部湾，振幅超过8 mm。在研究海区内，全日潮的垂向位移负荷潮不出现无潮点。自吸−负荷潮分布特征与垂向位移负荷潮相近，其振幅大约是垂向位移负荷潮的1.2～1.7倍，其位相与垂向位移负荷潮基本上相反。M2自吸−负荷潮最大振幅值也出现台湾海峡和加里曼丹岛西北外海，其值分别超过24 mm和18 mm。Abstract: The loading tides in the South China Sea and adjacent straits are calculated by means of the Green’s function method based on a high-resolution regional ocean tide model for the South China Sea, the DTU10 global ocean tide model, and the Gutenberg-Bullen A Earth model. The results show that the maximum amplitude of M2 vertical displacement loading (VDL) tide exceeding 18 mm appears in the Taiwan Strait; the second maximum exceeding 14 mm appears off the north-west coast of Kalimantan. The maximum amplitudes of the K1 and O1 VDL tides, exceeding 18 mm and 14 mm respectively, appear near the southern South China Sea; the second maximum exceeding 8 mm, appears in the Beibu Gulf. The distribution patterns of self-attraction and loading (SAL) tides are very similar to those of VDL tides in that the SAL tides have amplitudes about 1.2 times to 1.7 times the corresponding VDL tides and have phases basically opposite to corresponding VDL tides. The maximum amplitude of M2 SAL tide also appears in the Taiwan Strait and off the north-west coast of Kalimantan, with a magnitude exceeding 24 mm and 18 mm respectively.
-
图 1 南海及邻近海峡地形分布
Fig. 1 Topographical distribution of the South China Sea and adjacent straits
图 3 南海及邻近海峡分潮同潮图
虚线为振幅（单位：cm）；实线为格林威治迟角（单位：（°））
Fig. 3 Cotidal charts for the South China Sea and adjacent straits
Dashed lines indicate amplitude (unit: cm); solid lines indicate Greenwich phase-lag (unit: (°))
图 4 M2（a）和S2（b）垂向位移负荷潮
虚线为振幅（单位：mm）；实线为格林威治迟角（单位：（°））
Fig. 4 M2 (a) and S2 (b) vertical displacement loading tides
Dashed lines indicate amplitude (unit: mm); solid lines indicate Greenwich phase-lag (unit: (°))
图 7 K1（a）和O1（b）自吸−负荷潮
虚线为振幅（单位：mm）；实线为格林威治迟角（单位：（°））
Fig. 7 K1 (a) and O1 (b) self-attraction and loading tides
Dashed lines indicate amplitude (unit: mm); solid lines indicate Greenwich phase-lag (unit: (°))
图 5 K1（a）和O1（b）垂向位移负荷潮
虚线为振幅（单位：mm）；实线为格林威治迟角（单位：（°））
Fig. 5 K1 (a) and O1 (b) vertical displacement loading tides
Dashed lines indicate amplitude (unit: mm); solid lines indicate Greenwich phase-lag (unir: (°))
-
[1] Stepanov V N, Hughes C W. Parameterization of ocean self-attraction and loading in numerical models of the ocean circulation[J]. Journal of Geophysical Research, 2004, 109(C3): C03037. doi: 10.1029/2003JC002034 [2] Fang Guohong, Xu Xiaoqing, Wei Zexun, et al. Vertical displacement loading tides and self-attraction and loading tides in the Bohai, Yellow, and East China Seas[J]. Science China Earth Sciences, 2013, 56(1): 63−70. doi: 10.1007/s11430-012-4518-9 [3] Teng Fei, Fang Guohong, Xu Xiaoqing. Effects of internal tidal dissipation and self-attraction and loading on semidiurnal tides in the Bohai Sea, Yellow Sea and East China Sea: a numerical study[J]. Chinese Journal of Oceanology and Limnology, 2017, 35(5): 987−1001. doi: 10.1007/s00343-017-6087-4 [4] Apecechea M, Verlaan M, Zijl F, et al. Effects of self-attraction and loading at a regional scale: a test case for the Northwest European Shelf[J]. Ocean Dynamics, 2017, 67(6): 729−749. doi: 10.1007/s10236-017-1053-4 [5] 姜锦东, 方国洪, 滕飞, 等. 内潮耗散与自吸−负荷潮对南海潮波影响的数值研究[J]. 海洋与湖沼, 2018, 49(3): 457−470.Jiang Jindong, Fang Guohong, Teng Fei, et al. Dissipation and self-attraction and loading of internal tides: impact on the tidal waves in the South China Sea[J]. Oceanologia et Limnologia Sinica, 2018, 49(3): 457−470. [6] Schindelegger M, Green J A M, Wilmes S B, et al. Can we model the effect of observed sea level rise on tides?[J]. Journal of Geophysical Research, 2018, 123(7): 4593−4609. doi: 10.1029/2018JC013959 [7] Adhikari S, Ivins E R, Frederikse T, et al. Sea-level fingerprints emergent from GRACE mission data[J]. Earth System Science Data, 2019, 11(2): 629−646. doi: 10.5194/essd-11-629-2019 [8] 汪一航, 方国洪, 魏泽勋, 等. 基于卫星高度计的全球大洋潮汐模式的准确度评估[J]. 地球科学进展, 2010, 25(4): 353−359.Wang Yihang, Fang Guohong, Wei Zexun, et al. Accuracy assessment of global ocean tide models base on satellite altimetry[J]. Advances in Earth Science, 2010, 25(4): 353−359. [9] Stammer D, Ray R D, Andersen O B, et al. Accuracy assessment of global barotropic ocean tide models[J]. Reviews of Geophysics, 2014, 52(3): 243−282. doi: 10.1002/2014RG000450 [10] Zhou Xuhua, Wu Bin, Zhu Yaozhong, et al. The ocean tidal displacement corrections for earth crust movement network of China[J]. Chinese Astronomy and Astrophysics, 2002, 26(1): 81−87. doi: 10.1016/S0275-1062(02)00046-2 [11] 许厚泽, 毛伟建. 中国大陆的海洋负荷潮汐改正模型[J]. 中国科学B辑, 1988(9): 984−994.Xu Houze, Mao Weijian. The correction model of ocean load tides in Chinese continent[J]. Science in China (B), 1988(9): 984−994. [12] 郑祎, 伍吉仓, 王解先, 等. 海潮模型和格林函数对海潮位移改正的影响[J]. 大地测量与地球动力学, 2002, 22(4): 71−76.Zheng Yi, Wu Jicang, Wang Jiexian, et al. Effect of ocean tide model and Green function on ocean tidal displacement correction[J]. Journal of Geodesy and Geodynamics, 2002, 22(4): 71−76. [13] 周江存, 许厚泽, 孙和平. 中国台湾地区海洋负荷潮汐对重力、位移、倾斜和应变固体潮观测的影响[J]. 大地测量与地球动力学, 2002, 22(1): 81−86.Zhou Jiangcun, Xu Houze, Sun Heping. Influence of ocean load tides on gravity, displacement, tilt and strain in Taiwan[J]. Journal of Geodesy and Geodynamics, 2002, 22(1): 81−86. [14] 袁林果, 丁晓利, 孙和平, 等. 利用GPS技术精密测定香港海潮负荷位移[J]. 中国科学: 地球科学, 2010, 53(7): 993−1007. doi: 10.1007/s11430-010-3076-2Yuan Linguo, Ding Xiaoli, Sun Heping, et al. Determination of ocean tide loading displacements in Hong Kong using GPS technique[J]. Science China: Earth Sciences, 2010, 53(7): 993−1007. doi: 10.1007/s11430-010-3076-2 [15] 杜文成, 袁林果, 张宁宁, 等. 青岛台站重力固体潮和海潮负荷特征研究[J]. 大地测量与地球动力学, 2018, 38(9): 913−916, 942.Du Wencheng, Yuan Linguo, Zhang Ningning, et al. Study of Earth’s gravity tide and oceanic loading characteristics at Qingdao station[J]. Journal of Geodesy and Geodynamics, 2018, 38(9): 913−916, 942. [16] 赵红. 海潮负荷效应及利用GPS技术建立海潮负荷位移模型研究[J]. 测绘学报, 2018, 47(1): 133. doi: 10.11947/j.AGCS.2017.20170181Zhao Hong. Research on ocean tide loading and ocean tide loading displacement model estimated by GPS[J]. Acta Geodaetica et Cartographica Sinica, 2018, 47(1): 133. doi: 10.11947/j.AGCS.2017.20170181 [17] 王继刚, 周江存. 沿海和岛屿重力海潮负荷改正模型——以马祖岛为例[J]. 大地测量与地球动力学, 2020, 40(8): 794−798.Wang Jigang, Zhou Jiangcun. Correction model of ocean tide loading on gravity over coastal area and islands: a case study of Matzu Island[J]. Journal of Geodesy and Geodynamics, 2020, 40(8): 794−798. [18] Huang Pingping, Sulzbach R L, Tanaka Y, et al. Anelasticity and Lateral Heterogen-eities in Earth’s upper mantle: impact on surface displacements, self-attraction and loading, and ocean tide dynamics[J]. Journal of Geophysical Research, 2021, 126(9): e2021JB022332. doi: 10.1029/2021JB022332 [19] 陈宗镛. 潮汐学[M]. 北京: 科学出版社, 1980.Chen Zongyong. Tidology[M]. Beijing: Science Press, 1980. [20] 方国洪, 郑文振, 陈宗镛, 等. 潮汐和潮流的分析和预报[M]. 北京: 海洋出版社, 1986.Fang Guohong, Zheng Wenzhen, Chen Zongyong, et al. Analysis and Prediction of Tides and Tidal Currents[M]. Beijing: China Ocean Press, 1986. [21] 黄祖珂, 黄磊. 潮汐原理与计算[M]. 青岛: 中国海洋大学出版社, 2005.Huang Zuke, Huang Lei. Tidal Theory and Calculation[M]. Qingdao: China Ocean University Press, 2005. [22] Wahr J M. Body tides on an elliptical, rotating, elastic and oceanless Earth[J]. Geophysical Journal International, 1981, 64(3): 677−703. doi: 10.1111/j.1365-246X.1981.tb02690.x [23] Farrell W E. Deformation of the Earth by surface loads[J]. Reviews of Geophysics, 1972, 10(3): 761−797. doi: 10.1029/RG010i003p00761 [24] Francis O, Mazzega P. Global charts of ocean tide loading effects[J]. Journal of Geophysical Research, 1990, 95(C7): 11411−11424. doi: 10.1029/JC095iC07p11411 [25] Agnew D C. NLOADF: a program for computing ocean-tide loading[J]. Journal of Geophysical Research, 1997, 102(B3): 5109−5110. doi: 10.1029/96JB03458 [26] Agnew D C. SPOTL: some programs for ocean-tide loading. User’s Manual Version 3.3. 0[R]. US: Scripps Institution of Oceanography, 2012. [27] Ray R D. Ocean self-attraction and loading in numerical tidal models[J]. Marine Geodesy, 1998, 21(3): 181−192. doi: 10.1080/01490419809388134 [28] Fang Guohong, Wang Yonggang, Wei Zexun, et al. Empirical cotidal charts of the Bohai, Yellow, and East China Seas from 10 years of TOPEX/Poseidon altimetry[J]. Journal of Geophysical Research, 2004, 109(11): C11006. doi: 10.1029/2004JC002484 [29] Cheng Yongcun, Andersen O B. Multimission empirical ocean tide modeling for shallow waters and polar seas[J]. Journal of Geophysical Research, 2011, 116(C11): C11001. -
