珠江蕉门分汊河口分流比水槽实验研究

姚鹏 余志斌 苏敏 安欣禧 周曾

姚鹏,余志斌,苏敏,等. 珠江蕉门分汊河口分流比水槽实验研究[J]. 海洋学报,2022,44(x):1–10 doi: 10.12284/hyxb2022055
引用本文: 姚鹏,余志斌,苏敏,等. 珠江蕉门分汊河口分流比水槽实验研究[J]. 海洋学报,2022,44(x):1–10 doi: 10.12284/hyxb2022055
Yao Peng,Yu Zhibin,Su Min, et al. Flume experiment on flow division ratio of bifurcated Jiaomen outlet in the Pearl River Delta[J]. Haiyang Xuebao,2022, 44(x):1–10 doi: 10.12284/hyxb2022055
Citation: Yao Peng,Yu Zhibin,Su Min, et al. Flume experiment on flow division ratio of bifurcated Jiaomen outlet in the Pearl River Delta[J]. Haiyang Xuebao,2022, 44(x):1–10 doi: 10.12284/hyxb2022055

珠江蕉门分汊河口分流比水槽实验研究

doi: 10.12284/hyxb2022055
基金项目: 国家自然科学基金(51809296,51709288);河口海岸学国家重点实验室开放基金资助项目(SKLEC-KF202006);中央高校基本科研业务费项目(2019B04514,2019B05914);江苏省“双创博士”项目;河海大学优秀硕士学位论文培育计划。
详细信息
    作者简介:

    姚鹏(1987-),男,山东省菏泽市人,副教授,博士,主要从事河口海岸水沙动力方面研究。E-mail:p.yao@hhu.edu.cn

    通讯作者:

    苏敏(1986-),女,副教授,博士,主要研究河口海岸动力地貌演变方面研究。E-mail:sumin@hhu.edu.cn

  • 中图分类号: P737.1

Flume experiment on flow division ratio of bifurcated Jiaomen outlet in the Pearl River Delta

  • 摘要: 珠江蕉门承泄西北江的径流泥沙,为珠江主要的泄洪排沙口门,与虎门通过横向汊道凫洲水道连通,其分水分沙的比例对粤港澳大湾区防洪及通航安全至关重要。针对凫洲水道分流比问题,本文基于蕉门分汊河口的形态特点及地貌特征,设计系列水槽实验,探究凫洲水道分流比、分流比影响因子及其变化趋势等。结果表明:在保证宽度比、深度比和流量比均相似的情况下,该水槽实验可较高精度的模拟蕉门分汊河口分流比。凫洲水道分流比受到蕉门与虎门共同影响:虎门与蕉门的相对流速比越大,凫洲水道分流比越大,其主汊地位越明显。在现有的地貌特征条件下,凫洲水道主支汊转变的阈值是虎门与蕉门相对流速比为0.35。研究成果可为蕉门整治、保障其行洪通航安全等提供参考依据。
  • 图  1  珠江三角洲蕉门与虎门、凫洲水道位置示意图

    Fig.  1  The location of Jiaomen and Humen outlets, Fuzhou channel of the Zhujiang River Delta

    图  2  水槽模型设计及仪器布置平面图(a)与正视图(b)

    Fig.  2  Flume experiment design and instruments layout: top view (a) and front view (b)

    图  3  控制断面分布图

    Fig.  3  Control section distribution

    图  4  凫洲水道分流比随断面流速比的变化

    Fig.  4  Variation of flow division ratio of Fuzhou channel with velocity ratio between Humen and Jiaomen

    图  5  凫洲水道分流比及分流流量随虎门、蕉门流速比变化(虎门流速不变)

    Fig.  5  The relationship between variation of flow division ratio, water discharge of Fuzhou channel and flow discharge of Jiaomen(in case of constant Humen velocity)

    表  1  伶仃洋东四口门水沙分配表[19]

    Tab.  1  Distribution of water and sediment discharge of the east four outlets in the Lingding Bay

    口门径流量/亿m3占四大口门/%悬沙输沙量/万t占四大口门/%
    虎门57834.699527.2
    蕉门54132.4132336.1
    洪奇门20012.048913.3
    横门35121.085723.4
    总计16701003664100
    下载: 导出CSV

    表  2  实验工况设计表

    Tab.  2  Parameter setting of series of experimental scenarios

    工况V1/cm·s−1V2/cm·s−1V1/V2
    14200.2
    28200.4
    310200.5
    412200.6
    5(基准实验)16200.8
    6(基准实验)20201
    724201.2
    82418.51.3
    924141.7
    1024122
    1124102.4
    下载: 导出CSV

    表  3  实验分流比结果数据

    Tab.  3  Measured flow division ratio under different scenarios

    工况设计流速比V1/V2实测流速比V1/V2断面5分流比μ
    10.200.2020.45
    20.400.4270.54
    30.500.5910.58
    40.600.6460.61
    5(基准实验)0.800.7490.62
    6(基准实验)1.001.0320.75
    71.201.2210.77
    81.301.2880.80
    91.801.7730.91
    102.001.9400.98
    112.402.3410.99
    下载: 导出CSV
  • [1] 金元欢, 沈焕庭. 分汊河口形成的基本条件[J]. 海洋湖沼通报, 1991(4): 1−9.

    Jin Yuanhuan, Shen Huanting. Basic conditions for the formation of branching estuaries[J]. Transactions of Oceanology and Limnology, 1991(4): 1−9.
    [2] 孙志林, 金元欢. 分汊河口的形成机理[J]. 水科学进展, 1996, 7(2): 144−150. doi: 10.3321/j.issn:1001-6791.1996.02.009

    Sun Zhilin, Jin Yuanhuan. Mechanism of formation of an anabranched estuary[J]. Advances in Water Science, 1996, 7(2): 144−150. doi: 10.3321/j.issn:1001-6791.1996.02.009
    [3] 金元欢. 河口分汊的定量表达及其基本模式[J]. 地理学报, 1990, 45(1): 56−67. doi: 10.3321/j.issn:0375-5444.1990.01.006

    Jin Yuanhuan. Quantitative properties and classification models of branching estuaries[J]. Acta Geographica Sinica, 1990, 45(1): 56−67. doi: 10.3321/j.issn:0375-5444.1990.01.006
    [4] 闾国年, 贾建军, 宋志尧, 等. 从潮能通量变化看6000a以来长江口的迁移[J]. 海洋地质与第四纪地质, 1999, 19(4): 1−10.

    Lü Guonian, Jia Jianjun, Song Zhiyao, et al. Changes of the Yangtze River estuary since 6000 a B. P. estimated from tidal energy flux change[J]. Marine Geology & Quaternary Geology, 1999, 19(4): 1−10.
    [5] 陈吉余, 恽才兴, 徐海根, 等. 两千年来长江河口发育的模式[J]. 海洋学报, 1979, 1(1): 103−111.

    Chen Jiyu, Yun Caixing, Xu Haigen, et al. The developmental model of the Chang Jiang River estuary during last 2000 years[J]. Haiyang Xuebao, 1979, 1(1): 103−111.
    [6] 贺松林. 长江河口下段分汊口的组构模式[J]. 海洋学报, 2000, 22(1): 84−92.

    He Songlin. Combination mode of branching portions in downstream of the Changjiang estuary[J]. Haiyang Xuebao, 2000, 22(1): 84−92.
    [7] 巩彩兰, 恽才兴. 长江河口洪水造床作用[J]. 海洋工程, 2002, 20(3): 94−97. doi: 10.3969/j.issn.1005-9865.2002.03.016

    Gong Cailan, Yun Caixing. Floods rebuilding the riverbed of the Changjiang estuary[J]. The Ocean Engineering, 2002, 20(3): 94−97. doi: 10.3969/j.issn.1005-9865.2002.03.016
    [8] 施野, 张国安. 近50年长江口南、北港及附近分汊型河槽的演变[J]. 海洋通报, 2015, 34(3): 260−266. doi: 10.11840/j.issn.1001-6392.2015.03.004

    Shi Ye, Zhang Guoan. Evolution of branching channels in the South and North Channel in the Changjiang estuary during the recent 50 years[J]. Marine Science Bulletin, 2015, 34(3): 260−266. doi: 10.11840/j.issn.1001-6392.2015.03.004
    [9] Dai Zhijun, Liu J T, Wei Wen, et al. Detection of the Three Gorges Dam influence on the Changjiang (Yangtze River) submerged delta[J]. Scientific Reports, 2014, 4(1): 6600.
    [10] 潘昀, 窦希萍, 丁磊, 等. 分汊河口治理研究综述[C]//第十七届中国海洋(岸)工程学术讨论会论文集(下). 南宁: 中国海洋工程学会, 2015: 7.

    Pan Yun, Dou Xiping, Ding Lei, et al. A review on the regulation of braided estuaries[C]//Proceedings of the 17th China Ocean (Shore) Engineering Symposium (2). Nanning: Chinese society of Ocean Engineering, 2015: 7.
    [11] 缴健, 高祥宇, 丁磊, 等. 分汊河口地貌演变对整治工程的响应[J]. 海洋工程, 2019, 37(3): 143−150.

    Jiao Jian, Gao Xiangyu, Ding Lei, et al. Response of the morphological evolution of bifurcated estuary to the regulation project[J]. The Ocean Engineering, 2019, 37(3): 143−150.
    [12] 王世俊, 李春初, 田向平. 蕉门口发育演变及其对南沙港的影响[J]. 泥沙研究, 2004(3): 59−63. doi: 10.3321/j.issn:0468-155X.2004.03.009

    Wang Shijun, Li Chunchu, Tian Xiangping. Evolvement of Jiaomen distributary estuary of the Pearl River and its influences on Nansha harbor[J]. Journal of Sediment Research, 2004(3): 59−63. doi: 10.3321/j.issn:0468-155X.2004.03.009
    [13] 吴小明, 蔡伟. 珠江口蕉门延伸段悬沙不淤流速的初步研究[J]. 人民珠江, 1993(3): 16−20.

    Wu Xiaoming, Cai Wei. Preliminary research of the non-silting flow rate of suspended sand in the extension section of the Jiaomen at the Pearl River estuary[J]. Pearl River, 1993(3): 16−20.
    [14] 黄希敏. 蕉门口的整治[J]. 人民珠江, 1988(2): 42−45.

    Huang Ximin. Regulation Scheme of Jiaomen estuary[J]. Pearl River, 1988(2): 42−45.
    [15] 胡晓张, 张宇琪, 陈军, 等. 蕉门河口当前治理思路探讨[J]. 人民珠江, 2018, 39(7): 22−26. doi: 10.3969/j.issn.1001-9235.2018.07.005

    Hu Xiaozhang, Zhang Yuqi, Chen Jun, et al. Discussion on current management ideas of Jiaomen estuary[J]. Pearl River, 2018, 39(7): 22−26. doi: 10.3969/j.issn.1001-9235.2018.07.005
    [16] 李春初, 雷亚平, 何为, 等. 珠江河口演变规律及治理利用问题[J]. 泥沙研究, 2002(3): 44−51. doi: 10.3321/j.issn:0468-155X.2002.03.008

    Li Chunchu, Lei Yaping, He Wei, et al. Evolutional processes of the Pearl River estuary and its protective regulation and exploitation[J]. Journal of Sediment Research, 2002(3): 44−51. doi: 10.3321/j.issn:0468-155X.2002.03.008
    [17] 陈文龙, 刘培, 陈军. 珠江河口治理与保护思考[J]. 中国水利, 2020(20): 36−39. doi: 10.3969/j.issn.1000-1123.2020.20.021

    Chen Wenlong, Liu Pei, Chen Jun. Thoughts on the regulation and protection for the Pearl River estuary[J]. China Water Resources, 2020(20): 36−39. doi: 10.3969/j.issn.1000-1123.2020.20.021
    [18] 窦希萍, 罗肇森. 潮汐河口治理研究[J]. 中国水利, 2007(1): 39−42. doi: 10.3969/j.issn.1000-1123.2007.01.015

    Dou Xiping, Luo Zhaosen. Research of treatment of estuary with tides[J]. China Water Resources, 2007(1): 39−42. doi: 10.3969/j.issn.1000-1123.2007.01.015
    [19] 韩西军, 杨树森. 珠江口鸡抱沙附近地形冲淤演变研究[J]. 水道港口, 2008, 29(5): 328−332. doi: 10.3969/j.issn.1005-8443.2008.05.006

    Han Xijun, Yang Shusen. Scour and silting evolution of topography around Jibaosha in the Zhujiang estuary[J]. Journal of Waterway and Harbor, 2008, 29(5): 328−332. doi: 10.3969/j.issn.1005-8443.2008.05.006
    [20] 钟德馨. 浅探蕉门及洪奇沥的口门治理[J]. 人民珠江, 1989(2): 44−48,43.

    Zhong Dexin. Preliminary research on the regulation of Jiaomen estuary and Hongqili estuary[J]. Pearl River, 1989(2): 44−48,43.
    [21] 曾昭璇. 珠江三角洲地貌发育[M]. 广州: 暨南大学出版社, 2012: 100-101.

    Zeng Zhaoxuan. Geomorphological Development in the Pearl River Delta[M]. Guangzhou: Jinan University Press, 2012: 100−101.
    [22] 胡晓张, 王汉岗, 杨聿, 等. 高强度人类活动引起的蕉门口河势变化及规划治理对策研究[J]. 水利规划与设计, 2019(1): 12−18. doi: 10.3969/j.issn.1672-2469.2019.01.004

    Hu Xiaozhang, Wang Hangang, Yang Yu, et al. Research on the change of Jiaomen distributary estuary of the Pearl River regime caused by high intensity human activities and its planning and Control Countermeasures[J]. Water Resources Planning and Design, 2019(1): 12−18. doi: 10.3969/j.issn.1672-2469.2019.01.004
    [23] 杨聿, 胡晓张, 王汉岗, 等. 蕉门河口整治方案研究[J]. 人民珠江, 2019, 40(9): 39−47,55. doi: 10.3969/j.issn.1001-9235.2019.09.007

    Yang Yu, Hu Xiaozhang, Wang Hangang, et al. Study on regulation scheme of Jiaomen estuary[J]. Pearl River, 2019, 40(9): 39−47,55. doi: 10.3969/j.issn.1001-9235.2019.09.007
    [24] 刘杰, 陈吉余, 徐志扬. 长江口深水航道治理工程实施后南北槽分汊段河床演变[J]. 水科学进展, 2008, 19(5): 605−612. doi: 10.3321/j.issn:1001-6791.2008.05.001

    Liu Jie, Chen Jiyu, Xu Zhiyang. River-bed evolution in the braided reach of the south and north passage after implementing Yangtze estuary deepwater navigational improvements[J]. Advances in Water Science, 2008, 19(5): 605−612. doi: 10.3321/j.issn:1001-6791.2008.05.001
    [25] Zhu Boyuan, Li Yitian, Yue Yao, et al. Aggravation of north channels' shrinkage and south channels' development in the Yangtze Estuary under dam-induced runoff discharge flattening[J]. Estuarine, Coastal and Shelf Science, 2017, 187: 178−192. doi: 10.1016/j.ecss.2016.10.048
    [26] Marra W A, Parsons D R, Kleinhans M G, et al. Near-bed and surface flow division patterns in experimental river bifurcations[J]. Water Resources Research, 2014, 50(2): 1506−1530. doi: 10.1002/2013WR014215
    [27] 童朝锋. 分汊口水沙运动特征及三维水流数学模型应用研究[D]. 南京: 河海大学, 2005.

    Tong Chaofeng. Study on flow and sediment movement of bifurcation area and related application of 3-D numerical flow model[D]. Nanjing: Hohai University, 2005.
    [28] 罗宪林, 杨清书, 贾良文, 等. 珠江三角洲网河河床演变[M]. 广州: 中山大学出版社, 2002: 100-105.

    Luo Xianlin, Yang Qingshu, Jia Liangwen, et al. River Bed Evolution of the Pearl River Delta[M]. Guangzhou: Sun Yat-Sen University Press, 2002: 100−105.
    [29] 黄镇国, 张伟强. 珠江河口近期演变与滩涂资源[J]. 热带地理, 2004, 24(2): 97−102. doi: 10.3969/j.issn.1001-5221.2004.02.001

    Huang Zhenguo, Zhang Weiqiang. Recent evolution of the Zhujiang estuary and tidal flat resource[J]. Tropical Geography, 2004, 24(2): 97−102. doi: 10.3969/j.issn.1001-5221.2004.02.001
    [30] 何用, 胡晓张, 孙倩文. 从“05·6”洪水看珠江河口水沙输移[J]. 人民珠江, 2008(3): 10−14. doi: 10.3969/j.issn.1001-9235.2008.03.004

    He Yong, Hu Xiaozhang, Sun Qianwen. Water and sediment transport in the Pearl River estuary from the "05·6" flood[J]. Pearl River, 2008(3): 10−14. doi: 10.3969/j.issn.1001-9235.2008.03.004
    [31] 辛文杰. 伶仃洋西岸浅滩建港条件分析[J]. 水利水运工程学报, 2010(1): 9−15. doi: 10.3969/j.issn.1009-640X.2010.01.002

    Xin Wenjie. Analysis on the conditions of harbor construction at Lingdingyang west bay[J]. Hydro-Science and Engineering, 2010(1): 9−15. doi: 10.3969/j.issn.1009-640X.2010.01.002
    [32] 侯爱中, 胡智丹, 黄建波, 等. 2015~2019年西江编号洪水分析[J]. 水文, 2021, 41(1): 90-94.

    Hou Aaizhong, Hu Zhidan, Huang Jianbo, et al. Analysis of the numbered floods in Xijiang during 2015-2019[J] Journal of China Hydrology, 2021, 41(1): 90−94.
    [33] 郑斌鑫, 诸裕良, 于东生, 等. 珠江口八大口门径、潮作用动力过程研究[J]. 海洋科学进展, 2010, 28(1): 1−7. doi: 10.3969/j.issn.1671-6647.2010.01.001

    Zheng Binxin, Zhu Yuliang, Yu Dongsheng, et al. Dynamic process effected commonly by runoff and tide at the eight main entrances to the Pearl River estuary[J]. Advances in Marine Science, 2010, 28(1): 1−7. doi: 10.3969/j.issn.1671-6647.2010.01.001
    [34] 何杰. 潮汐河口汊道治理数值模拟研究[D]. 南京: 南京水利科学研究院, 2006.

    He J. Study on regulation for tidal estuary inlet by mathematical simulation[D]. Nanjing: Nanjing Hydraulic Research Institute, 2006.
    [35] 金元欢, 沈焕庭. 科氏力对河口分汊的影响[J]. 海洋科学, 1993(4): 52−56.

    Jin Yuanhuan, Shen Huanting. Effects of Criolis’ force on estuarine branch fiord[J]. Marine Sciences, 1993(4): 52−56.
    [36] 肖洋, 王艳, 徐辉荣, 等. 珠江三角洲“洪水就近入海”防洪治理方案探讨[J/OL]. 河海大学学报(自然科学版): 1-10.

    Xiao Yang, Wang Yan, Xu Huirong, et al. Analysis on the flood control scheme for “flood discharge from the nearer route” of the Pearl River Delta[J/OL]. Journal of Hohai University (Natural Sciences): 1−10.
