日本海中尺度涡旋时空变化特征研究

杨霄 张永垂 夏长水 董昌明 胡楠 汪浩笛 陈诗尧

杨霄,张永垂,夏长水,等. 日本海中尺度涡旋时空变化特征研究[J]. 海洋学报,2022,44(6):1–16 doi: 10.12284/hyxb2022035
引用本文: 杨霄,张永垂,夏长水,等. 日本海中尺度涡旋时空变化特征研究[J]. 海洋学报,2022,44(6):1–16 doi: 10.12284/hyxb2022035
Yang Xiao,Zhang Yongchui,Xia Changshui, et al. Spatiotemporal variations of mesoscale eddies in the Japan Sea[J]. Haiyang Xuebao,2022, 44(6):1–16 doi: 10.12284/hyxb2022035
Citation: Yang Xiao,Zhang Yongchui,Xia Changshui, et al. Spatiotemporal variations of mesoscale eddies in the Japan Sea[J]. Haiyang Xuebao,2022, 44(6):1–16 doi: 10.12284/hyxb2022035

日本海中尺度涡旋时空变化特征研究

doi: 10.12284/hyxb2022035
基金项目: 国家重点研发计划(2017YFA0604100);国家自然科学基金(41406003);江苏省自然科学基金(BK20130064)。
详细信息
    作者简介:

    杨霄(1997-),女,甘肃省庆阳市人,主要从事物理海洋学研究。E-mail:yx@nuist.edu.cn

    通讯作者:

    张永垂,男,江苏省沐阳县人,副教授,主要从事海洋环流动力学和海洋中尺度涡研究。E-mail:zyc@nudt.edu.cn

    董昌明,男,安徽省黄山市人,教授,主要从事物理海洋、海洋动力学和数值模拟研究。E-mail:cmdong@nuist.edu.cn

  • 中图分类号: P714+.1

Spatiotemporal variations of mesoscale eddies in the Japan Sea

  • 摘要: 本文利用1993—2019年基于海表面高度异常的涡旋数据集和高度计数据统计分析了日本海区域中尺度涡旋的大小、极性、生命周期、振幅、传播等表面特征的时空变化规律。27年间,共探测到1 429个涡旋,气旋和反气旋数量基本相当,其中气旋675个,反气旋754个。两种极性涡旋均具有较强的季节变化:秋季较多,冬季次之,春季最少。郁陵盆地、大和盆地等为涡旋多发区域呈现西南-东北向带状分布。其中,南部海域反气旋占优,靠近津轻海峡的北部海域气旋占优。西部和南部受东韩暖流和对马暖流的驱动,涡旋移动方向与流场基本一致,北部涡旋与黎曼寒流以及副极地锋流有关。研究表明,动力学不稳定是涡旋在秋冬季大量产生的重要原因。此外,半封闭盆地、局地流场以及复杂的海气相互作用等都可能会对涡旋的产生和消亡造成一定影响。
  • 图  1  日本海地形(a)和表层环流示意图(b)

    UB.郁陵盆地;YB.大和海盆;JB.日本海盆;KS.对马(朝鲜)海峡;TsS.津轻海峡;SS.宗谷海峡;TaS.鞑靼海峡;YR.大和隆起。b图红色箭头代表暖流,黑色箭头代表寒流;NB.对马暖流近岸分支;OB.对马暖流离岸分支;EKWC.东韩暖流;LCC.黎曼寒流;NKCC.北韩寒流; SPFC.副极地锋流

    Fig.  1  Topographic map of the Japan Sea from ETOO2 (a) and schematic diagram of the Japan Sea surface current (b)

    UB. Ulleung Basin; YB. Yamato Basin; JB. Japan Basin; KS. Korea Strait; TsS. Tsugaru Strait; SS. Soya Strait; TaS. Tatarsky Strait; YR. Yamato Rise. In b, the red arrow represents warm current and black arrow represents cold current; NB.Tsushima Warm Current Nearshore Branch; OB. Tsushima Warm Current Offshore Branch; EKWC. East Korean Warm Current; LCC. Liman Cold Current; NKCC. North Korea Cold Current; SPFC. Subpolar Front Current

    图  2  涡动能(a)和海表面高度异常均方根(b)多年平均空间分布

    Fig.  2  Spatial distribution of the multi-year average eddy kinetic energy ( a) and root mean square of the sea level anomaly ( b)

    图  3  涡动能(EKE)和海表面高度异常均方根(SLA RMS)(a,c)及其线性增长率(b,d)的时间变化序列

    上、下行分别为年际和季节变化,a和c中的阴影部分为误差范围

    Fig.  3  Time series of eddy kinetic energy (EKE) and sea surface height anomaly root mean square (SLA RMS) (a, c) and its linear growth rate (b, d)

    The up and down rows are interannual and seasonal variations respectively, and the shaded part in a and c is the error range

    图  4  涡旋数量的年际(a)和月变化(b)

    纵坐标为不同极性涡旋占总涡旋数的比值

    Fig.  4  The interannual (a) and monthly (b) variation of eddy numbers

    Vertical axis is the ratio of eddies with different polarities to the total number of eddies

    图  5  涡旋数量在0.1°×0.1°网格内的空间分布

    图a为气旋图,b为反气旋,背景颜色为涡旋数量,黑线轮廓线为500 m等深线

    Fig.  5  Spatial distribution of average eddy number over 0.1°×0.1° bins

    a is cyclonic eddies and b is anticyclonic eddies. The background color is the number of eddies and the outline of the black line is the 500 m isobath line

    图  6  涡旋生命周期(a、e、f)、半径(b、f、j)、振幅(e、g、k)和旋转速度(d、h、l)分布)

    顶部、中部和底部的行分别是累积曲线图、柱状图和气旋与反气旋的比值图,其中第二行为不同极性涡旋占总涡旋的比值,第三行比值图中虚线表示1

    Fig.  6  Distribution of eddy life cycle (a, e, f), radius (b, f, j), amplitude (e, g, k), and rotation velocity (d, h, l)

    The top, middle, and bottom rows are cumulative curves, bars, and cyclonic eddies to anticyclonic eddies ratios, respectively. The second row is the ratio of eddies with different polarities to the total number of eddies,and the dotted line in the third row of ratio graph indicates 1.

    图  7  涡旋半径(左列)、振幅(中列)和旋转速度(右列)在0.5°×0.5°网格内的空间分布

    上、下行分别为气旋和反气旋,黑色轮廓线为500 m等深线

    Fig.  7  Spatial distribution of eddy radius (left column), amplitude (middle column) and rotation velocity (right column) in a 0.5°×0.5° grid

    The upper and lower lines are cyclonic eddies and anticyclonic eddies respectively, and the black line contour line is 500 m isobath line

    图  8  半径(a,b)、振幅(c,d)和旋转速度(e,f)的年际(a,c,e)和季节(b,d,f)变化

    阴影部分为统计检验,由$u \pm \sigma (t)/\sqrt {N(t)} $计算所得,µ表示为平均值,$\sigma $为标准差,N为数据量

    Fig.  8  Interannual (a, c, e) and seasonal (b, d, f) variations of eddy radius (a, b), amplitude (c, d) and rotation velocity (e, f)

    The shaded part is the statistical test, which is calculated  by $u \pm \sigma (t)/\sqrt {N(t)} $, µ is the mean value, $\sigma $ is the standard deviation, and N is the data amount

    图  9  涡旋半径(a)、振幅(b)和旋转速度(c)随生命周期的演变

    点为各参数的实际结果,实线则为对应参数的傅里叶拟合结果

    Fig.  9  Time evolution of the mean normalized eddy radii (a), amplitude (b) and rotation velocity (c)

    The point is the actual result of each parameter, and the solid line is the Fourier fitting result of the corresponding parameter

    图  10  气旋(a)和反气旋(b)在0.5°×0.5°网格内的传播示意图

    箭头代表相对传播方向,各线条为不同传播路径示意图

    Fig.  10  Schematic diagram of cyclonic eddies (a) and anticyclonic eddies (b) propagation in a 0.5°×0.5° grid

    The arrow represents the relative propagation direction, and each line is the schematic diagram of different propagation paths

    图  11  涡旋纬向和经向的平均传播速度

    东向传播速度随纬度(a)、经度(b)的变化北向传播速度随纬度(c)、经度(d)的变化)虚线表示速度零度线

    Fig.  11  Zonal and meridional average propagation speeds of eddies.

    Eastward speed variationwith (a) latitude and (b) longitude. Northward speed variation with (c) latitude and (d) longitude. )The dotted line indicates that the speed is 0

    图  12  气旋(a)和反气旋(b)相对传播轨迹和涡旋北向(c)、东向(d)移动的概率分布

    黑色虚线为零度线,c,d中坐标为不同极性涡旋占总涡旋数比值

    Fig.  12  Probability distribution of relative trajectories of cyclonic eddies (a) and anticyclonic eddies (b) and eddies moving northward (c) and eastward (d)

    The black dotted line is the zero line.γ-axis in c and d is the ratio of eddies with different polarities to the total number of eddies

    图  13  气旋(a,c,e)和反气旋(b,d,f)在0.5°×0.5°的网格内的空间分布图

    左列为涡旋产生、中间为涡旋消亡、右列为涡旋生消比值,正值表示涡旋生成数大于涡旋消亡数,值大小为生成数/消亡数;负值表示涡旋消亡数大于生成数,值大小为消亡数/生成数

    Fig.  13  Spatial distribution of cyclonic eddies (a,c,e) and anticyclonic eddies (b,d,f) in a 0.5°×0.5° grid

    The left column is eddy generation, the middle column is eddy extinction, and the right column is eddy generation-extinction ratio. The positive value is that the number of eddy generation is greater than the number of eddy extinction, and the value is the generation/extinction number. A negative value means that the number of eddies dying is greater than the number of generation, and the value is the number of eddies dying/number of generation.

    图  14  涡旋产生和消亡的年际变化(a,b)与季节变化(c,d)

    (a、c)表示涡旋产生;(b、d)表示涡旋消亡,纵坐标为不同极性涡旋占总涡旋数的比值

    Fig.  14  Interannual variation (a, b) and seasonal variation (c, d) of eddy generation and extinction

    a and c represent the generation of eddies. b and d represent the extinction of eddies. and γ-axis is the ratio of eddies with different polarities to the total number of eddies

    图  15  研究区域内经向SST梯度的年际变化(a)和季节变化(b)

    a中黑线表示1993—2019年月平均经向SST梯度,红线表示13个月的滑动平均;b中黑线表示经向SST梯度的季节变化,红线表示反气旋的月平均产生数量比率,蓝线表示气旋的月平均产生数量比率。CC数值代表相关系数,SG表示SST梯度,CG和AG分别表示气旋和反气旋的产生百分比,撇号表示各变量6—12月的相关系数

    Fig.  15  Interannual variation (a) and seasonal variation (b) of the SST gradient in the study area

    a. The middle black line represents the monthly average meridional SST gradient from 1993 to 2019, and the red line represents the 13-month moving average; b.The middle black line shows the seasonal variation of the meridional SST gradient , the red line shows the ratio of the average monthly number of anticyclonic eddies and the blue line shows the ratio of the average monthly number of cyclonic eddies. The CC value represents the correlation coefficient, SG represents the SST gradient, CG and AG represent the percentage of cyclone and anticyclone eddy generation respectively, and the apostrophe represents the correlation coefficient of each variable from 6 to 12 months
